Product Introduction:Shenzhen BORHEE Technology Development Co., Ltd. has launch

Product Introduction:

Shenzhen BORHEE Technology Development Co., Ltd. has launched a 96 well Magnetic Separation Rack, which can efficiently separate various types of magnetic beads. By inserting the 96 well PCR plate into the magnetic plate, the magnetic separation process can be completed in an average of 30 seconds, achieving the goal of rapid separation and purification of substances such as cells, proteins, or nucleic acids. The tube of the 96 hole magnetic plate can be just close to the magnet, making your separation process intuitive and convenient. This magnetic frame is the preferred product for purifying and enriching PCR products in second-generation sequencing. Especially its high-performance magnets have better adsorption ability for Ampure XP magnetic beads.

Technical parameters:

Specification (mm): 127 × 85 × 15

Aperture: Suitable for 96 well PCR plates

Working volume: 1-200ul

Recommended centrifuge tube: Suitable for all brands of 96 PCR plates on the market. The magnetic frame with protective edge on the side has been optimized to pull magnetic beads to the side in porous reaction plates. The feature of the magnetic frame is equipped with 6 bar type magnetic frames, which are compatible with most 96 well PCR reaction plates with edge protection, culture dishes, 96 well round bottom plates, 96 well flat bottom plates, 24 well plates, 12 well plates, and 6-well plates (not recommended for use with 48 well plates). Working volume per well (5-200 µ L).

Please note that the size of the reaction plate may vary, and you should test the compatibility of your reaction plate.

Operation:

1. Place the centrifuge tube containing the mixture of magnetic beads to be separated and the target substance on a magnetic plate.

2. Keep still for 30 seconds until all magnetic beads are drawn to the wall of the eight row tube or 96PCR plate.

3. Carefully pour out the liquid or use a pipette to aspirate the liquid.

4. Remove the centrifuge tube from the magnetic plate and place it back on the regular centrifuge tube holder to complete the magnetic separation operation.

Application features:

1. A small-scale specialized magnetic separation tool designed for biological experiments, suitable for antibody purification, immunoprecipitation, immunoprecipitation, cell sorting, nucleic acid separation, and other operations.

2. Reasonable design and convenient operation. High magnetic field strength, fast separation. The average magnetic separation time is 30 seconds, and the separation process is fast and efficient.

3. Compact, lightweight, and durable. The unique material makes the magnetic frame lightweight yet durable.

4. Suitable for high-throughput and rapid purification of nucleic acids. The purified nucleic acid can be directly added to an eight row tube or a 96 PCR plate with PCR reaction solution for PCR reaction, which can quickly and easily perform PCR amplification operations.

Application image:

1. Can be used for 96 well PCR plates

2. Suitable for various 96 well PCR plates, directly place the 96 well PCR plate into the magnetic plate. With clever process design, the plate can be easily fixed and not easily dropped out

3. Magnetic bead adsorption situation
